Machinery Componets

DC motor in φ33 mm OD and 6-12 Voltage operating range can be adjusted, surely with high RPM, convenient in speed control, easy to install, high in starting torque, long life span advantages. It can be applied to coin exchange machine, grabber machine, powered respirator, power-assisted bicycle, massage tool, smart door lock and lab equipment.

Specializing in the manufacture of various aluminum-magnesium alloy and other material sample models and 3D printing, product model making, ID design, product 3D mechanism design, 3-axis-5 axis CNC machining, metal model fixtures, silicone temporary molds, Special rapid mold, sheet metal laser production, laser engraving, screen printing, transfer paper, aluminum nameplate production, so far has more than 20 years of production experience.

We uphold the consistent philosophy, with the best technology and the most advanced equipment, we have been continuously expanding and enhancing the equipment, in order to create the highest quality products to serve customers.

Our customer base has expanded from the domestic market to China, Europe, America, Singapore, Japan, Australia and other places, and the production lineup has also been extended to have full-time industrial and Mechanical Designers, making us towards the goal of diversification.

Features
  • Output Shaft: Central / Eccentric Shaft
  • Spin Direction: Bi-Direction
  • Carbon Brush.
  • Magnet: Rubber Magnet / Ring-Shaped Permanent.
  • Low Noise, Low Energy Consumption.
  • High Durability, High Performance.
  • MIT / OEM.
  • Customized various speeds, torques, voltages, output shafts, etc.
Specification
  • Operating Voltage Range: DC3V ~ 24V
  • Gearbox OD: φ 21.5 - 22mm
  • DC Motor OD: φ 21 - 21.5mm
Motor Drawing
Micro electric motor dia. 22mm for liquid dispenser motor, Coffee maker and Cleaner robot.
Motors Test List
RATIO 9 17.4 18.8 39.2 70.6 81.7
DIM "L" MM 22.5 22.5 22.5 22.5 22.5 22.5
EFF 73 66 66 59 59 59
Allowable Torque(Kg-Cm) 0.2 0.3 0.6 0.8 0.8 0.8
